Features
A screw-fixing anchor exclusively for extruded cement boards.
The design eliminates the drill bit and maximizes the thickness of the attachment.
Can be installed in both hollow and solid parts.
By applying serrations to the back side of the thin washer head, it reduces head skipping during construction and tightens the parts firmly.
Use
For extruded cement boards.
For fixing piping saddles and metal fittings, etc.
Specification
Thread designation: 5.0
Thread length (mm): 25
Total length (mm): 33
Pilot hole diameter (mm): 4.0
Attachment thickness (mm): 8
Maximum tensile load (kN): 3.2
Maximum installation thickness (mm): 8
Underneck length (mm): 33
Maximum working length (mm): 25
Drilling diameter (mm): 4.0
Compatible bit: TB-2
Cross recess number: 2
Nominal diameter (mm): 5.0
Head height (mm): 2.2
Head diameter (mm): 12.0
Maximum tensile load (kN): 3.2
Accessories: Drill (AMD-4.095D) 1 piece
Specification2
In pack
ECP Association (Extruded Cement Plate Association) recommended product (nominal diameter 5.0/6.0mm)
Material/Finish
Stainless steel (SUS410)
Surface treatment: SPAC treatment
Set contents/accessories
Amera drill (AMD-4.095D) 1 piece
caution
Maximum tensile load is the catalog value when using Amera Drill on extruded cement board 60mm thick.
