ICM Controls ICM455 3-Phase Monitor 100-fault Memory with Time/Date Stamp LCD Setup and Diagnostics

Product Description

The ICM455 is a programmable 3-phase line voltage monitor from ICM Controls. It features a backlit LCD, 100 fault memory, and a real-time clock for accurate timestamps. The operating range is 190-600 VAC with a control voltage of 18-240 VAC. It monitors both the line and load sides of the system, ensuring full protection for your power, motor, and contactor lines.

• Programmable with a 7-step push-button setup
• Monitors voltage unbalance, phase loss, and more
• Includes backup supply to record brownout conditions for up to 4 hours

Product Highlights

This monitor ensures your system operates within safe parameters, reducing risks of damage to electrical components.

Product Information

Standard Information

• Brand: ICM Controls
• Control Voltage: 18-240 VAC

Technical Specifications

• Weight: 0.7 pounds
• Height: 1.5 inches
• Width: 4.5 inches
• Length: 5.5 inches
• Maximum Voltage: 600 VAC
• Full Load Amps: 10
• Phase: Three
• Cycle/Hertz: 50/60 Hz
