Product Description
The Johnson Controls M9208-BAC-3 is a 120VAC direct coupled actuator designed for reliable operation. This actuator provides a force of 70 lb-in and features a spring-return system. Suitable for various HVAC applications, it ensures precise control of dampers and airflow management.
- Reversible mounting for flexible installation
- Electronic stall detection for safe operation
- Microprocessor-controlled brushless DC motor for efficiency
Product Highlights
Built for durability with double insulated construction and integral cables. Comes with a locking manual override for easy manual control when necessary.
Product Information
Standard Information
- Brand: Johnson Controls
- Part Number: M9208-BAC-3
Technical Specifications
- Power Consumption: 0.5 Amp running, 0.3 Amp holding
- Operating Conditions: -40F to 140F (-40C to 60C)
- Electrical Connection: 48 inch 18 AWG appliance cable with integral 3/8 inch FMC connectors
- Auxiliary Switch: 2 SPDT
- Housing: NEMA 2, IP54
