Product Description
The KMC CONTROLS CSC-2001 Reset Volume Controller is designed for VAV terminal units in HVAC systems. This controller optimizes air velocity with separate adjustment settings for maximum and minimum limits, enhancing HVAC efficiency.
- Includes dual adjustment knobs for customized airflow management.
- Features push-on fittings for easy installation with quarter-inch O.D. tubing.
- Engineered with ABS material for durability and long service life.
Product Highlights
Equipped with a robust mounting bracket, the CSC-2001 is tailored for direct-action mechanisms suitable for normally open units. It also accommodates reverse-action setups for normally closed units. Its performance is calibrated using advanced airflow measuring tools.
Product Information
Standard Information
- Brand: KMC CONTROLS
- MPN: CSC-2001
Technical Specifications
- Main Air Pressure (PSIG): 15 to 30 PSIG
- Max. Signal Pressure (Inch WC): 6
- Operating Temperature Limit (F): 40 to 120 Degrees F
- Air Consumption: 14.4 SCIM at 20 PSIG
- Output Sensitivity (Inch WC): 0.02 at 5 PSI
- Connection Ports: Push On Fittings For 1/4 In O.D. Tubing
- Included Accessories: HFO-0006/SSS-1000 Series Flow Sensors, G3103877, G2673806, G0349912, G1468153
